Description
Achieve professional-quality hinge installations with ease using this hinge jig. The quick-clamping mechanism firmly secures the jig to the work surface, minimising movement and ensuring perfect alignment. Whilst the internal structure features two precision-bearing guide drill bit shanks, which ensure smooth and accurate hole-making. Paired with a high-hardness alloy blade drill bit for clean and effortless hole cutting. Moreover, it features a limiting ring, which ensures precise depth control and prevents over-drilling. Perfect for fitting concealed hinges, making repairs, DIY, or assembling new furniture with its easy operation.
Features
• Crafted from robust aluminium alloy for long-lasting durability and resistance to wear.
• Quick-release clamp with an anti-slip textured pad ensures firm and secure positioning.
• Suitable for 15mm - 25mm thick wooden boards, ideal for most cabinet and furniture doors.
Specifications
Hinge Jig Dimension: 16.7cm W x 5.6m D x 9.8m H
Wrench Dimension: 7cm W x 2m D
Hex Key Dimension: 7cm W x 6m D
Product Type: Hinge Jig
Material: Aluminium Alloy
Colour: Blue+Silver
Hole Diameter: 35mm
Hole to Edge Distance: 5mm
Suitable Wood Thickness: 15-25mm
Drill Bit Size: 35mm/2mm
Package Content
1 x Hinge Jig
1 x 35MM Drill Bit
1 x 2mm Drill Bit
2 x Wrenches
1 x Hex Key
Package Specifications
Package Dimension(WxDxH): 19 x 11 x 6cm
Gross Weight: 0.64kg
How to Use:
1. Adjust the drilling depth of the limit ring, normally 12-13mm.
2. Adjust the size to adapt to the thickness of the clamped board.
3. Quickly clamp the locking plate according to the drill mark.
4. Drill 35mm and left and right 2mm screw holes
5. Install hinge
Notes
-Applicable wood board thickness at 12-25mm.
-Drilling depths of 12-13 mm, controlled and locked by adjusting the limit ring according to the depth of the hinge fixture.
-35MM hinge opener only supports the use of 35mm opening drill bit, does not support the exchange of 40mm. 35mm hole to the edge is 5mm, suitable for most common hinge jigs.
-When not in use, keep it tidy check if the accessories are collected and place it in a dry place.
-Despite efforts for accuracy, there may be some reasonable error due to manual measurement.
-Actual product colours may vary due to monitor settings & lightings.
